Mechanical Considerations
The MicroPAC power supply can be mounted on four of the six surfaces using
standard 6-32 screws with a maximum torque of 7 inch-lb.
When using the mounting points the maximum insertion depth of the screw
into the chassis from the outside surface must not exceed 0.125”.
When considering a mounting location and/or orientation it is important not
to restrict the air flow entering and exiting the MicroPAC. Air is drawn into the
MicroPAC through the fan guard located next to the input power connector at the
rear of the power supply and exhausts through the load side of the power supply
next to the LED display panel. Westcor recommends a minimum clearance of 2”
be kept at the front and rear of the MicroPAC.
Care should be taken to minimize the output cabling as not impede the air
exhausting from the MicroPAC, the output screw securing the cabling to the
output terminals should be torque to 15 inc-lb not to exceed 20 inc-lb.
Product Description
The MicroPAC is a factory configurable power supply providing up to 1,300 W of
continuous power in a small slimline 1 u package. The power supply provides
up to 4 isolated outputs and combines power factor correction along with high efficiency
and power density. The MicroPAC boasts a power density of 25 Win 3 and efficiency up
to 92%, the power supply is available in a wide temperature range configuration and
for harsh environments and mil-cots applications conformal coated. All configurations
carry full safety agency approvals i.E. Ul60950 en60950 and are CE marked.
The MicroPAC power supply platform supports a wide range of customer power
requirements and is especially suited for distributed power architectures. The design
offers a small flexible cost-effective solution for applications requiring high efficiency
and power density. The isolated outputs may be placed in parallel/series configurations
with automatic current sharing. For applications requiring higher power levels the
MicroPAC's can be configured in arrays with box to box current sharing.
Applications Include
n  Factorized power architectures
n  Distributed bus architectures
n  Industrial
n  Automation equipment
Standard Features
n  High efficiency up to 92%
n  Small Size
n  Printing
n  MIL-COTS applications
n  Telecommunications
n  Renewable energy
n  Output series capability
n  Output current sharing
n  High power density (25
W/In 3 )
n  MicroPAC to MicroPAC current sharing
n  Up to 1300 W
(Configuration dependent)
n  Low power standby mode
(Green mode)
n  Universal Input
(85 to 264 Vac) (47 to 400 Hz)
n  Power shed capability
n  Vibration MIL-STD 810-F
  Figure 514.5C-17
n  Overtemperature warning
n  Overtemperature shutdown
vicorpower.com
Applications Engineering: 800 927.9474
Page 2
